Terminal /
Transformer Bushings

High-performance Epoxy Resin / Porcelain Cast Bushings for transformers, switchgear, and power distribution equipment. IEP manufactures durable and reliable terminal bushings designed for safe current transfer and superior electrical insulation in low, medium, and high-voltage applications.

Engineered with premium epoxy resin and precision-machined Copper, Brass, or Steel conductors, our bushings offer excellent dielectric strength, mechanical stability, moisture resistance, and long service life.

Request a Quote → View Gallery

Key Specifications

Up to 72.5kV Up to 10,000A IS/DIN/BS
Features

Key Features

Durable and reliable bushings for power transmission and distribution

High Dielectric Strength

Excellent insulation reliability for safe current transfer in low, medium, and high-voltage applications.

Robust Epoxy Resin / Porcelain Construction

Premium materials ensure superior mechanical stability and long service life.

Indoor & Outdoor Applications

Suitable for a wide range of environments and installation conditions.

Custom Conductor & Mounting Configurations

Tailored designs to meet specific customer requirements and applications.

Tin, Nickel, Silver Plated or Natural Finish

Multiple finishing options for conductors to suit your application needs.

Low Maintenance & Long Service Life

Designed for reliable performance with minimal maintenance requirements.

Specifications

Technical Specifications

Comprehensive range of voltage and current ratings

Parameter Details
Voltage Ratings 1 kV – 3 kV – 12 kV – 36 kV – 52 kV – 72.5 kV
Current Ratings 250 A – 630 A – 1000 A – 2000 A – 3150 A – 4500 A – 5000 A – 8000 A – Up to 10,000 A
Materials Epoxy Resin / Porcelain Casting
Conductor Materials Copper, Brass, Steel (as per specification)
Finishes Tin Plated, Nickel Plated, Silver Plated, Natural
Standards IS 3347, DIN 42530-42531-42532, BS 2562, Customer Specifications
Applications Distribution, Power, Dry-Type, Furnace, Locomotive, Cast Resin, CT, PT, Industrial Transformers, Switchgear, Electrical Panels

* Custom designs available as per customer drawings and specifications

Applications

Industrial Applications

Trusted across diverse industrial sectors

⚡ Distribution Transformers 🏭 Power Transformers 🔥 Dry-Type Transformers 🔥 Furnace Transformers 🚄 Locomotive Transformers ⚡ Cast Resin Transformers ⚡ CT & PT Transformers 🔌 Switchgear 📊 Electrical Panels 🏭 Industrial Transformers
Trusted By

Trusted by Industry Leaders

Trusted by transformer manufacturers, utilities, railways, steel plants, and heavy industries for dependable power transmission and distribution solutions.

Manufactured to IS, DIN, BS, and customer specifications with complete ready-to-install supply packages.

Request a Quote →
Quality Assured

IS 3347 & DIN Compliant

Premium Epoxy Resin & Porcelain Bushings

Terminal / Transformer Bushings

High-performance bushings for transformers, switchgear, and power distribution equipment. Voltage ratings up to 72.5kV and current ratings up to 10,000A.
